ID | OD | W.P | B.P | B.R. | Weight | Length |
mm | inch | mm | psi | bar | psi | bar | mm | Kg/m | ft | m |
19 | 3/4" | 34.4 | 315 | 21 | 945 | 63 | 100 | 0.95 | 200 | 61 |
25 | 1" | 40.4 | 255 | 17 | 765 | 51 | 150 | 1.16 | 200 | 61 |
32 | 1-1/4" | 49 | 210 | 14 | 630 | 42 | 190 | 1.61 | 200 | 61 |
38 | 1-1/2" | 55 | 157 | 10.5 | 471 | 31.5 | 220 | 1.85 | 200 | 61 |
51 | 2" | 68 | 105 | 7 | 315 | 21 | 300 | 2.36 | 200 | 61 |
64 | 2-1/2" | 81.6 | 60 | 4 | 180 | 12 | 380 | 3.03 | 200 | 61 |
76 | 3" | 94.4 | 60 | 4 | 180 | 12 | 450 | 3.85 | 200 | 61 |
102 | 4" | 120.2 | 60 | 4 | 180 | 12 | 550 | 5.21 | 200 | 61 |
NOTE: Other parameters are by your requirements.
