Steel Wire High Pressure Resin Hose SAE100 R7

CONSTRUCTION: This hose consists of an inner tube of oil synthetic rubber,a single fiber braid reinforcement ,an oil and weather resistant rubber cover.

APPLICATIONS: Suitable for conveying hydraulic fluids such as glycol, mineral oil, lubrcation, emulsion, hydrocarbons etc, Water and air can not be used for conveying phosphate ester groups.

WORKING TEMPERATTUER:From -40℃ up to +100℃,the conveying medium temperature can be 0℃ to 70℃ if it is water.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Series	Nominal Diameter	Size	ID	OD	W.P	B.P	Min.B.R
R7	mm	inch	min	max	Mpa	Mpa	mm
R7-3-05	5	3/16“	4.8	9.8	35.0	140.0	30
R7-4-06	6	1/4“	6.3	12.7	27.5	110.0	40
R7-5-08	8	5/16”	7.9	14.3	25.0	100.0	55
R7-6-10	10	3/8“	10.3	15.9	22.5	90.0	65
R7-8-12.5	12.5	1/2“	12.7	19.8	17.5	70.0	85
R7-10-16	16	5/8“	15.9	23.3	14.0	56.0	115
R7-12-19	19	3/4”	19.0	26.5	12.0	48.0	140
R7-16-25	25	1“	25.4	34.0	10.0	40.0	180
R7-4-06	6	1/4“	6.3	13.3	35.0	140.0	40
R7-5-08	8	5/16”	7.9	15.0	32.5	130.0	50
R7-6-10	10	3/8“	10.3	18.0	29.0	116.0	70
R7-8-12.5	12.5	1/2”	12.7	21.6	26.0	104.0	80
R7-10-16	16	5/8“	15.9	23.6	20.0	80.0	130
R7-12-19	19	3/4”	19.0	26.4	17.5	70.0	160
R7-16-25	25	1“	25.4	34.0	12.0	48.0	220

NOTE: Other parameters are by your requirements.
