SAE 100 R5 hydraulic hose is a premium single wire braid reinforced hydraulic solution designed for demanding industrial applications. Constructed with an oil-resistant synthetic rubber inner tube, a single high-tensile steel wire braid reinforcement, and a durable oil and weather resistant rubber cover, this hose delivers reliable performance in harsh operating environments. Our SAE 100 R5 rubber hose is engineered to meet the strict SAE J517 standards, ensuring consistent quality and compatibility with standard hydraulic systems worldwide.
This high pressure hydraulic hose R5 is ideal for conveying a wide range of hydraulic fluids including glycol, mineral oil, lubricants, emulsions, and hydrocarbons. It operates effectively within a temperature range of -40℃ to +100℃ for most hydraulic fluids, and 0℃ to 70℃ for water-based media. Please note that this hose is not suitable for conveying phosphate ester-based fluids. Available in 12 standard sizes from 5mm (3/16") to 76mm (3") nominal diameter, our SAE 100 R5 oil resistant hose can be customized to meet your specific length and assembly requirements.
The single high-tensile steel wire braid reinforcement provides superior pressure handling capabilities, making our industrial hydraulic hose SAE 100 R5 perfect for medium to high pressure hydraulic systems. With working pressures ranging from 1.4 MPa to 21.0 MPa and burst pressures 4 times the working pressure, this hose ensures safe and reliable operation even under peak load conditions.
The oil and weather resistant rubber cover protects against abrasion, ozone, and UV exposure, extending the service life of the hose in outdoor and industrial environments. The synthetic rubber inner tube offers excellent resistance to hydraulic fluids, preventing degradation and ensuring long-term performance.
With 12 standard sizes available, our SAE 100 R5 hydraulic hose can accommodate virtually any hydraulic system requirement. From small diameter hoses for precision equipment to large diameter hoses for heavy machinery, we have the right solution for your application.
The flexible design of our single wire braid hydraulic hose allows for easy routing and installation in tight spaces. It is compatible with standard hydraulic fittings, ensuring quick and hassle-free assembly.
Product Series | Nominal Diameter | Size | ID | OD | W.P | B.P | W.T | ||
R5 | mm | inch | min | max | min | max | Mpa | Mpa | Kg/m |
R5-3-05 | 5 | 3/16“ | 4.6 | 5.5 | 12.5 | 13.5 | 21.0 | 84.0 | 0.20 |
R5-4-06 | 6 | 1/4“ | 6.1 | 7.2 | 14.1 | 15.1 | 21.0 | 84.0 | 0.25 |
R5-5-08 | 8 | 5/16” | 7.9 | 8.7 | 16.2 | 17.4 | 15.7 | 62.8 | 0.31 |
R5-6-10 | 10 | 3/8“ | 10.3 | 11.1 | 18.4 | 19.6 | 14.0 | 56.0 | 0.36 |
R5-8-12.5 | 12.5 | 1/2“ | 12.7 | 13.7 | 22.2 | 23.8 | 12.2 | 48.8 | 0.45 |
R5-10-16 | 16 | 5/8” | 15.9 | 17.0 | 26.2 | 27.8 | 10.5 | 42.0 | 0.60 |
R5-14-22 | 22 | 7/8“ | 22.2 | 23.3 | 30.0 | 32.2 | 5.6 | 22.4 | 0.70 |
R5-18-28 | 28 | 1-1/8” | 28.6 | 29.8 | 36.3 | 38.8 | 4.3 | 17.2 | 0.85 |
R5-22-35 | 35 | 1-3/8“ | 34.9 | 36.1 | 42.8 | 45.2 | 3.5 | 14.0 | 1.00 |
R5-28-46 | 46 | 1-3/4” | 46.0 | 47.2 | 54.3 | 56.7 | 2.4 | 9.6 | 1.40 |
R5-38-61 | 61 | 2-3/8“ | 60.3 | 61.9 | 70.8 | 73.2 | 2.4 | 9.6 | 2.16 |
R5-48-76 | 76 | 3” | 76.2 | 77.8 | 88.3 | 90.7 | 1.4 | 5.6 | 2.84 |
Note: Custom specifications are available upon request.
Our SAE 100 R5 hydraulic hose is widely used in various industrial sectors where reliable hydraulic power transmission is essential. It is commonly found in:
Construction machinery including excavators, bulldozers, and cranes
Agricultural equipment such as tractors, harvesters, and irrigation systems
Manufacturing machinery and production lines
Material handling equipment including forklifts and conveyor systems
Mining equipment and machinery
Marine and offshore applications
Automotive and transportation systems
This hose is particularly suitable for applications that require medium to high pressure hydraulic fluid transfer, where durability and reliability are critical factors.
The maximum working temperature is +100℃ for most hydraulic fluids. For water-based media, the temperature range is 0℃ to 70℃.
No, this hose is not compatible with phosphate ester-based fluids. We recommend using a hose specifically designed for phosphate ester applications.
The burst pressure is 4 times the working pressure for all sizes of SAE 100 R5 hydraulic hose.
Yes, we can provide custom cut lengths and complete hose assemblies with fittings to meet your specific requirements.
Our SAE 100 R5 hydraulic hose meets the SAE J517 industry standard, ensuring compatibility with standard hydraulic systems worldwide.
