Sinohydr SAE100 R16 compact wire braided hydraulic hose is engineered for high-pressure hydraulic systems where space is at a premium. This advanced hydraulic solution features a robust construction with an oil-resistant synthetic rubber inner tube, one or two layers of high-tensile steel wire braid reinforcement, and a durable oil and weather-resistant rubber cover. Designed to meet the stringent SAE 100 R16 industry standard, our compact hydraulic hose delivers exceptional performance in confined spaces without compromising on pressure capacity or durability.
Our SAE100 R16 hydraulic hose is manufactured using state-of-the-art production techniques to ensure consistent quality and reliable operation in demanding industrial environments. The compact design reduces overall hose diameter by approximately 20% compared to standard R1 and R2 hoses, making it ideal for applications where tight bends and limited installation space are common challenges. Available in eight standard sizes ranging from 1/4" to 1-1/4" nominal diameter, this high-pressure compact hydraulic hose offers versatile solutions for a wide range of hydraulic systems.
The most significant advantage of our SAE100 R16 compact wire braided hose is its space-saving construction. By optimizing the reinforcement layer design and using high-strength steel wire, we have achieved a significantly smaller outer diameter while maintaining equivalent pressure ratings to standard hydraulic hoses. This allows for tighter routing, reduced system weight, and improved overall equipment efficiency.
Our compact wire braided hydraulic hose delivers impressive pressure capabilities, with working pressures ranging from 11.3 MPa to 35.0 MPa and burst pressures from 45.2 MPa to 140.0 MPa. The high-tensile steel wire braid reinforcement provides excellent resistance to pressure surges and impulse loads, ensuring long service life even in the most demanding hydraulic applications.
Operating reliably from -40°C to +120°C for hydraulic fluids and 0°C to 70°C for water-based media, our SAE100 R16 hydraulic hose is suitable for use in diverse climatic conditions and industrial environments. The synthetic rubber compounds used in both the inner tube and outer cover are specially formulated to maintain flexibility and performance across this broad temperature spectrum.
The oil-resistant synthetic rubber inner tube provides excellent compatibility with most common hydraulic fluids, while the oil and weather-resistant outer cover protects against abrasion, ozone, and UV damage. This robust construction ensures that our compact hydraulic hose can withstand the rigors of daily industrial use, reducing maintenance costs and downtime.
Product Series | Nominal Diameter | Size | ID | W.D | OD | W.P | B.P | Min.B.R | W.T | |||
R16 | mm | inch | min | max | min | max | min | max | Mpa | Mpa | mm | Kg/m |
R16-04-06 | 6.3 | 1/4“ | 6.2 | 7 | 10.6 | 12.3 | 12.6 | 13.8 | 35.0 | 140.0 | 50.0 | 0.27 |
R16-05-08 | 8 | 5/16" | 7.7 | 8.5 | 12.1 | 13.3 | 14.4 | 15.6 | 29.7 | 118.0 | 55.0 | 0.35 |
R16-06-10 | 10 | 3/8" | 9.3 | 10.1 | 14.5 | 15.9 | 16.4 | 17.6 | 28.0 | 112.0 | 65.0 | 0.42 |
R16-08-12.5 | 12.5 | 1/2” | 12.3 | 13.5 | 17.5 | 19.0 | 19.9 | 21.1 | 24.5 | 98.0 | 90.0 | 0.50 |
R16-10-16 | 16 | 5/8“ | 15.5 | 16.7 | 20.6 | 22.6 | 23.2 | 24.8 | 21.0 | 84.0 | 100.0 | 0.65 |
R16-12-19 | 19 | 3/4'' | 18.6 | 19.8 | 24.6 | 26.3 | 27.2 | 28.8 | 21.0 | 84.0 | 120.0 | 0.80 |
R16-16-25 | 25 | 1'' | 25 | 26.4 | 32.5 | 34.0 | 34.1 | 36.5 | 14.0 | 56.0 | 150.0 | 1.22 |
R16-20-32 | 32 | 1-1/4'' | 31.4 | 33.0 | 39.3 | 41.9 | 42.8 | 45.2 | 11.3 | 45.2 | 210.0 | 1.49 |
Note: Custom specifications are available upon request to meet your specific application requirements.
Our SAE100 R16 compact wire braided hydraulic hose is widely used in various industrial sectors where space optimization and high-pressure performance are critical. It is particularly suitable for:
Construction machinery and equipment
Agricultural machinery and tractors
Material handling equipment including forklifts and cranes
Mining equipment and machinery
Industrial hydraulic systems and power units
Mobile hydraulic applications
Machine tools and manufacturing equipment
This hose is designed to convey common hydraulic fluids such as glycol, mineral oil, lubrication oil, emulsion, and hydrocarbons. It is important to note that it should not be used for conveying phosphate ester-based fluids.
SAE100 R16 hoses feature a compact design with a smaller outer diameter compared to standard R1 and R2 hoses while maintaining equivalent pressure ratings. This makes them ideal for applications with limited installation space.
Our compact wire braided hydraulic hose is compatible with most common hydraulic fluids including glycol, mineral oil, lubrication oil, emulsion, and hydrocarbons. It should not be used with phosphate ester-based fluids.
The SAE100 R16 hydraulic hose can operate at temperatures from -40°C to +120°C when conveying hydraulic fluids. For water-based media, the temperature range is 0°C to 70°C.
Yes, we offer custom cut lengths and a wide range of compatible fittings to meet your specific application needs. Our technical team can also provide custom hose assemblies tailored to your requirements.
We offer flexible order quantities to accommodate both small and large-scale industrial customers. Please contact our sales team for detailed pricing and MOQ information.
